Anchor Windlasses

We manufacture hydraulic and electric windlass with pulling capacities from 900kg up to 5,000kgs. You can choose from our range of styles and sizes below or we can design and manufacture a customised windlass to your specification.

Model ID

Max Pull (Kgs)

Chain Size (mm)

Pressure (Bar)

Flow (lpm)

Price

Model ID: M1

Max Pull (Kgs): 900

Chain Size (mm): 8-12

Pressure (Bar): 140

Flow (lpm): 15

Price: £4005.75

More Details...

Model ID: M2 DG or GD

Max Pull (Kgs): 2000

Chain Size (mm): 8-16

Pressure (Bar): 160

Flow (lpm): 25

Price: £5381.25

More Details...

Model ID: M2 DGGD

Max Pull (Kgs): 2000

Chain Size (mm): 8-16

Pressure (Bar): 160

Flow (lpm): 25

Price: £6682.20

More Details...

Model ID: M3

Max Pull (Kgs): 3000

Chain Size (mm): 14-20

Pressure (Bar): 160

Flow (lpm): 40

Price: £9594.90

More Details...

Model ID: M5

Max Pull (Kgs): 5000

Chain Size (mm): 16-26

Pressure (Bar): 160

Flow (lpm): 50

Price: £11676.00

More Details...

Model ID: V3

Max Pull (Kgs): 3000

Chain Size (mm): 12-16

Pressure (Bar): 160

Flow (lpm): 40

Price: £POA

More Details...

Model ID: V3.5

Max Pull (Kgs): 3500

Chain Size (mm): 12-18

Pressure (Bar): 160

Flow (lpm): 50

Price: £POA

More Details...

Model ID: V5

Max Pull (Kgs): 5000

Chain Size (mm): 16-30

Pressure (Bar): 160

Flow (lpm): 55

Price: £POA

More Details...

For technical drawings and more information on each product please use the 'More Details' button next to the model you require more information for.
